Availability: | |
---|---|
1 | Visual appearance | Visual inspection | Ribbed inside & smooth outside surface, free from blisters, shrink hole, flaking, scratches & roughness. |
2 | Outer diameter | FCST | 5.0mm ± 0.1mm |
3 | Wall thickness | FCST | 0.75mm ± 0.10mm |
4 | Inner diameter clearance | Blowing steel ball | A 3.0mm steel ball can be blown freely through the duct. |
5 | Ovality | FCST | ≤ 7% |
6 | Pressurization | 5 minutes @12 bar each duct | No damage and leakage |
7 | Kink | IEC 60794-1-2 Method E10 | ≤ 50mm |
8 | Tensile strength | Rate of extension: 100mm/min | ≥ 60N |
9 | Impact | IEC 60794-1-2 Method E4 1.0 J Impact, recovery time 1 hour | No residual deformation > 15% of inner and outer diameter, shall pass inner diameter clearance test. |
10 | Min. bend radius | 60mm | No residual deformation > 15% of inner and outer diameter, shall pass inner diameter clearance test. |
1 | Visual appearance | Visual inspection | Ribbed inside & smooth outside surface, free from blisters, shrink hole, flaking, scratches & roughness. |
2 | Outer diameter | FCST | 5.0mm ± 0.1mm |
3 | Wall thickness | FCST | 0.75mm ± 0.10mm |
4 | Inner diameter clearance | Blowing steel ball | A 3.0mm steel ball can be blown freely through the duct. |
5 | Ovality | FCST | ≤ 7% |
6 | Pressurization | 5 minutes @12 bar each duct | No damage and leakage |
7 | Kink | IEC 60794-1-2 Method E10 | ≤ 50mm |
8 | Tensile strength | Rate of extension: 100mm/min | ≥ 60N |
9 | Impact | IEC 60794-1-2 Method E4 1.0 J Impact, recovery time 1 hour | No residual deformation > 15% of inner and outer diameter, shall pass inner diameter clearance test. |
10 | Min. bend radius | 60mm | No residual deformation > 15% of inner and outer diameter, shall pass inner diameter clearance test. |
