No obvious corrosion on the surface, qualityloss <1%
Mechanical Performance
Items
Standard No.
Requirements
Test Results
Tensile Strength
GB/T1447-2005
≥100MPa
105MPa
Tensile Modulus
GB/T1447-2005
≥10GPa
11.8GPa
Bending Strength
GB/T1449-2005
≥200MPa
213MPa
Flexural Modulus
GB/T1449-2005
≥10GPa
11.3GPa
Impact Toughness
GB/T1451-2005
≥80KJ/㎡
90.8KJ/㎡
Barr's Hardness
GB/T3854-2005
≥50
56
Chamber Load
Chamber Type
FCST-TH-SMC04
Axial Test Load
100KN
Lateral Test Load
40KN
Thermal Performance
Items
Standard No.
Test Results
Heat Distortion Temperature
GB/T1634.2-2004
> 200°C
Bending Strength
GB/T9979- 2005(-40°C)
265MPa
Flexural modulus
GB/T9979- 2005(-40°C)
1.43x10^(4)
MPa
Bending strength retention rate
GB/T9979- 2005(-40°C)
124%
Flexural modulus retention rate
GB/T9979- 2005(-40°C)
11.16%
Linear expansion coefficient
B/T2572-205 (26°C~100°C)
1.66x10^(-5)
<template class="visibility">
Product Specifications
All products comply with EN124:1994 standards.
Chemical Resistance Performance
Chemicals
Concentrated Sulfuric Acid
Sodium Hydroxide
Sodium Chloride
Test Conditions
Soaked in the specified solution for 48h
Test results
No obvious corrosion on the surface, qualityloss <1%
Mechanical Performance
Items
Standard No.
Requirements
Test Results
Tensile Strength
GB/T1447-2005
≥100MPa
105MPa
Tensile Modulus
GB/T1447-2005
≥10GPa
11.8GPa
Bending Strength
GB/T1449-2005
≥200MPa
213MPa
Flexural Modulus
GB/T1449-2005
≥10GPa
11.3GPa
Impact Toughness
GB/T1451-2005
≥80KJ/㎡
90.8KJ/㎡
Barr's Hardness
GB/T3854-2005
≥50
56
Chamber Load
Chamber Type
FCST-TH-SMC04
Axial Test Load
100KN
Lateral Test Load
40KN
Thermal Performance
Items
Standard No.
Test Results
Heat Distortion Temperature
GB/T1634.2-2004
> 200°C
Bending Strength
GB/T9979- 2005(-40°C)
265MPa
Flexural modulus
GB/T9979- 2005(-40°C)
1.43x10^(4)
MPa
Bending strength retention rate
GB/T9979- 2005(-40°C)
124%
Flexural modulus retention rate
GB/T9979- 2005(-40°C)
11.16%
Linear expansion coefficient
B/T2572-205 (26°C~100°C)
1.66x10^(-5)
</template>
Product Structure
<template class="visibility">
Product Structure
</template>
Product Size
Packing And Transportation
Packing description
Due to the structural characteristics of the product, the factory packaging can be selected according to the actual needs of customers,transportation distances, and transportation routes.
Disassembly and transportation
The structure of the product is simple and easy to disassemble, and all the components can be split into discrete parts, which arestacked and bundled flat. It occupies small space, low transportation cost, ,disassembly and bundling are more conducive toproduct stability, it is convenient to transport and goods damage is small.
Pallet Size
Product Weight（KG）
Pallet Capacity
Container Loading Capacity
(40GP container，Weight limit 26 tons)
FCST-TH-SMC04
(1100mmx1300mmx2200mm)
15
48sets
432sets
<template class="visibility">
Product Size
Packing And Transportation
Packing description
Due to the structural characteristics of the product, the factory packaging can be selected according to the actual needs of customers,transportation distances, and transportation routes.
Disassembly and transportation
The structure of the product is simple and easy to disassemble, and all the components can be split into discrete parts, which arestacked and bundled flat. It occupies small space, low transportation cost, ,disassembly and bundling are more conducive toproduct stability, it is convenient to transport and goods damage is small.
